AcoustiClip Concrete Ceiling System Soundproof Kit
From
£
332.65
ex. VAT
AcoustiClip Concrete Ceiling Quantities
AcoustiClip Concrete Ceiling Quantities
Quantity of materials supplied with the AcoustiClip Concrete Ceiling soundproofing system. Order over 20 sqm by adding additional combinations, for example, to order 35 sqm of this system, you can add 20m and 15m to the basket. The minimum order is 5 sqm.
| Area per sqm | DFM acoustic insulation 25mm/60kg 11.52sqm per pack | AcoustiClip | AcoustiChannel 1800mm | Noisestop 1+ Panel 18mm 1200mm x 1200mm | 15mm Acoustic plasterboard 1200mm x 1200mm | AC50 Acoustic sealant standard |
| 5 | 1 | 22 | 8 | 4 | 4 | 2 |
| 6 | 1 | 22 | 9 | 5 | 5 | 2 |
| 7 | 1 | 28 | 10 | 5 | 5 | 2 |
| 8 | 1 | 28 | 11 | 6 | 6 | 2 |
| 9 | 1 | 34 | 12 | 7 | 7 | 2 |
| 10 | 1 | 34 | 13 | 7 | 7 | 2 |
| 11 | 1 | 36 | 14 | 8 | 8 | 2 |
| 12 | 2 | 36 | 16 | 9 | 9 | 2 |
| 13 | 2 | 40 | 17 | 10 | 10 | 3 |
| 14 | 2 | 42 | 18 | 10 | 10 | 3 |
| 15 | 2 | 47 | 19 | 11 | 11 | 4 |
| 16 | 2 | 47 | 21 | 12 | 12 | 4 |
| 17 | 2 | 49 | 23 | 12 | 12 | 4 |
| 18 | 2 | 52 | 25 | 13 | 13 | 4 |
| 19 | 2 | 52 | 26 | 14 | 14 | 4 |
| 20 | 2 | 58 | 27 | 14 | 14 | 4 |
Quantities have been estimated on square ceilings, please check the quantities before ordering. If you are unsure of the quantities you require or need to alter the number of materials you need, you can order extra materials online or give us a call to discuss your options, call 01423 339163.
Product quantities are calculated by dividing the square meterage of the wall by the individual product dimensions. For example, the Noisestop1+ boards are 1200mm x 1200mm. This covers an area of 1.44m². To calculate how many boards you need for a 16m² wall, divide 16 by 1.44 = 11.11. Round up the figure to the next number, which gives you 12 boards. All quantities have been rounded up to the nearest unit or pack.
